LP-DL410 4” direct thermal label and barcode printer is ultra-compact and economical
GET YOUR QUOTE AND DETAILS
Supported payment types:
Overview
| Print Method | Direct Thermal |
| Print Speed | “SLP-DL410: Up to 5 ips (127 mm/sec)SLP-DL413: Up to 5 ips (127 mm/sec) “ |
| Print Resolution | “SLP-DL410: 203 dpiSLP-DL413: 300 dpi “ |
| Print Width | “SLP-DL410: Up to 108 mmSLP-DL413: Up to 105.7 mm” |
| Print Length | Up to 2,000 mm |
| Sensor | Transmissive, Reflective (Adjustable), Head Open |
| Media Characteristics | |
| Media Type | Gap, Black Mark, Notch, Continuous, Fan-Fold |
| Media Width | 25 ~ 116 mm |
| Media Roll Diameter | External roll media options up to Ø 150 mm to 205 mm |
| Media Thickness | 0.06 ~ 0.20 mm |
| Supply Method | – |
| Inner Core | – |
| Ribbon Characteristics | |
| Ribbon Type | – |
| Ribbon Width | – |
| Ribbon Length | – |
| Core Inner Diameter | – |
| Physical Characteristics | |
| Dimensions (WxDxH) | “177 x 150 x 148.5 mm (6.97 x 5.91 x 5.85 inch)” |
| Weight | 1.6 kg (3.53 lbs.) |
| Electrical | “EnergyStar Certified, Internal Power Adaptor 100-240V AC, 50/60Hz” |
| Display | |
| Camera | |
| Performance Characteristics | |
| Memory | 64 MB SDRAM, 128 MB Flash |
| Interface | “Standard: USB+WLANOptional: ① USB+Ethernet+WLAN ② USB+Ethernet+WLAN+Bluetooth ③ USB+WLAN+Bluetooth————————————————————-WLAN: 802.11a/b/g/n/ac Dongle type – requires a USB Host port (Optional)Bluetooth: Built-in type, MFi iAP2 certified “ |
| Real Time Clock | Supported(Option) |
| Environment Characteristics | |
| Temperature | “Operating: 0 ~ 40℃ (32 ~ 104℉)Storage: -20 ~ 60℃ (-4 ~ 140℉)” |
| Humidity | “Operating: 10 ~ 80% RHStorage 10 ~ 90% RH” |
| Reliability | |
| Thermal Print Head (TPH) | |
| Auto Cutter | |
| Platen Roller | |
| Software | |
| Emulation | SLCS™, BPL-Z™ (ZPLII), BPL-E™ (EPL) |
| Driver/Utility | “Windows Driver (Europlus/Seagull)Linux/Mac CUPS DriverVirtual COM USB/Ethernet DriverUtility ProgramOPOS/JPOS DriverBartender Ultralite for BIXOLONLabel Artist-II™SAP® Device Driver” |
| SDK/Plugin | “Android/iOS/Windows SDK Linux SDKChrome SDKXamarin SDK” |
| Application | “Label Artist™Mobile (Android,iOS)mPrint App (iOS)mPrint Server (Windows, iOS)” |
| MDM(Optional) | BIXOLON Profile Manager – XPM™, XCM™ (Windows, Android) |
| Fonts/Graphics/Symbologies | |
| Fonts | 10 SLCS™ / One SLCS™ / 16 BPL-Z™ / One BPL-Z™ / 5 BPL-E™ / 23 Code Page / Unicode supported (UTF-8, UTF-16LE, UTF-16BE) |
| Graphics | Supporting user-defined fonts, graphics, formats and logos |
| Barcode Symbologies | “1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 “ |
| Accessories | |
| Standard | – |
| Optional | Peeler, Auto Cutter, External Paper Supply, External Power Adaptor, WLAN Dongle (Consensus required), USB cable |
