SLP-TX420 4” TT or DT desktop printer with optional WiFi
GET YOUR QUOTE AND DETAILS
Supported payment types:
Overview
| Print Method | Thermal Transfer, Direct Thermal |
| Print Speed | “SLP-TX420: Up to 7 ips (178 mm/sec)SLP-TX423: Up to 5 ips (127 mm/sec) “ |
| Print Resolution | “SLP-TX420: 203 dpiSLP-TX423: 300 dpi “ |
| Print Width | “SLP-TX420: Up to 108 mmSLP-TX423: Up to 105.7 mm” |
| Print Length | Up to 2,000 mm |
| Sensor | Transmissive, Reflective (Adjustable), Ribbon-End, Head Open |
| Media Characteristics | |
| Media Type | Gap, Black Mark, Notch, Continuous, Fan-Fold |
| Media Width | 20 ~ 110 mm |
| Media Roll Diameter | Up to 130 mm |
| Media Thickness | 0.06 ~ 0.20 mm |
| Supply Method | Easy Paper Loading |
| Inner Core | 25.4 ~ 38.1mm |
| Ribbon Characteristics | |
| Ribbon Type | Wax, Wax/Resin, Resin, Outside |
| Ribbon Width | 110 mm |
| Ribbon Length | Up to 74 m |
| Core Inner Diameter | 12.7 mm |
| Physical Characteristics | |
| Dimensions (WxDxH) | “200 x 252 x 173 mm (7.87 x 9.92 x 6.81 inch)” |
| Weight | 2.35 kg (5.18 lbs.) |
| Electrical | “EnergyStar Certified, External Power Adaptor 100-240V AC, 50/60Hz” |
| Display | |
| Camera | |
| Performance Characteristics | |
| Memory | 64 MB SDRAM, 128 MB Flash |
| Interface | “Standard: USB+Serial+ParallelOptional: ① USB+Serial+Ethernet+WLAN ② USB+WLAN+Bluetooth——————————————————-WLAN: 802.11a/b/g/n/ac Dongle type – requires a USB Host port (Optional)Bluetooth: Built-in type, MFi iAP2 certified “ |
| Real Time Clock | Supported(Option) |
| Environment Characteristics | |
| Temperature | “Operating: 5 ~ 40℃ (41 ~ 104℉) Storage: -20 ~ 60℃ (-4 ~ 140℉)” |
| Humidity | “Operating: 10 ~ 80% RHStorage 10 ~ 90% RH” |
| Reliability | |
| Thermal Print Head (TPH) | |
| Auto Cutter | |
| Platen Roller | |
| Software | |
| Emulation | SLCS™, BPL-Z™ (ZPLII), BPL-E™ (EPL) |
| Driver/Utility | “Windows Driver (Europlus/Seagull)Linux/Mac CUPS DriverVirtual COM USB/Ethernet DriverUtility ProgramOPOS/JPOS DriverBartender Ultralite for BIXOLONLabel Artist-II™SAP® Device Driver” |
| SDK/Plugin | “Android/iOS/Windows SDK Linux SDKChrome SDKXamarin SDK” |
| Application | “Label Artist™Mobile (Android,iOS)mPrint App (iOS)mPrint Server (Windows, iOS)” |
| MDM(Optional) | BIXOLON Profile Manager – XPM™, XCM™ (Windows, Android) |
| Fonts/Graphics/Symbologies | |
| Fonts | 10 SLCS™ / One SLCS™ / 16 BPL-Z™ / One BPL-Z™ / 5 BPL-E™ / 23 Code Page / Unicode supported (UTF-8, UTF-16LE, UTF-16BE) |
| Graphics | Supporting user-defined fonts, graphics, formats and logos |
| Barcode Symbologies | “1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 “ |
| Accessories | |
| Standard | – |
| Optional | Peeler, Auto Cutter, External Paper Supply,WLAN Dongle (Consensus required), Serial cable, Parallel cable, USB cable |
| Supplies |
