XD5-40 series is a 4-inch (118mm) mid-level DT and TT Desktop Barcode and Label Printer
GET YOUR QUOTE AND DETAILS
Supported payment types:
Overview
| Print Method | XD5-40d : Direct Thermal XD5-40t : Thermal Transfer or Direct Thermal |
| Print Speed | XD5-40d: Up to 7 ips (178 mm/sec) XD5-43d: Up to 5 ips (127 mm/sec) XD5-40t: Up to 6 ips (152 mm/sec) XD5-43t: Up to 4 ips (102 mm/sec) |
| Print Resolution | XD5-40d, 40t : 203 dpi XD5-43d, 43t : 300 dpi |
| Print Width | XD5-40t: Up to 108 mm XD5-43t: Up to 105.7 mm |
| Print Length | Up to 1,000 mm |
| Sensor | Transmissive(Fixed), Reflective(Adjustable), Head Open |
| Media Characteristics | |
| Media Type | Gap, Black Mark, Notch, Continuous, Fan-Fold |
| Media Width | 15~118mm |
| Media Roll Diameter | Up to 127mm |
| Media Thickness | 0.06 ~ 0.20 mm |
| Supply Method | Easy Paper Loading |
| Inner Core | 25.4 ~ 38.1mm |
| Ribbon Characteristics | |
| Ribbon Type | Wax, Wax/Resin, Resin, Outside |
| Ribbon Width | 33 ~ 110 mm |
| Ribbon Length | Up to 300 m |
| Core Inner Diameter | 25.4 mm, 12.7 mm |
| Physical Characteristics | |
| Dimensions (WxLxH) | XD5-40d: 194 x 248 x 169 mm (7.64 x 9.76 x 6.65 inch) XD5-40t:210 x 284 x 188 mm (8.3 x 11.2 x 7.4 inch) |
| Weight | XD5-40d: 1.89kg (4.17 lbs.) XD5-40t: 2.48kg (5.46 lbs.) |
| Electrical | EnergyStar Certified, External Power Adaptor 100-240V AC, 50/60Hz |
| Display | XD5-40d & XD5-40t Standard: None Optional: FSTN LCD (200 x 100 pixels) XD5-40tR Standard : FSTN LCD (200 x 100 pixels) |
| Camera | |
| Performance Characteristics | |
| Memory | “STD:64 MB SDRAM, 128 MB Flash Optional: ① 64 MB SDRAM, 128 MB Flash ② 256 MB SDRAM, 256 MB Flash ③ 256 MB SDRAM, 512 MB Flash |
| Interface | “Standard: USB +USB Host Optional: ① USB+USB Host+Serial+Ethernet ② USB+USB Host+Serial+Ethernet+WLAN ③ USB+USB Host+Serial+Ethernet+Bluetooth XD5-40tR (RFID) Standard: USB+USB Host+Serial+Ethernet Optional: ① USB+USB Host+Serial+Ethernet+WLAN ② USB+USB Host+Serial+Ethernet+Bluetooth ————————————————————— WLAN:802.11a/b/g/n (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) – WEP40/104, WPA1/2 (PSK, EAP) Bluetooth: V5.0 (MFi certified) Ethernet: 10/100Mbps” |
| Real Time Clock | Supported(Optional) |
| Environment Characteristics | |
| Temperature | “Operating: XD5-40d: 0 ~ 40℃ (32 ~ 104℉) XD5-40t: 5 ~ 40℃ (41 ~ 104℉) Storage: -20 ~ 60℃ (-4 ~ 140℉)” |
| Humidity | “Operating: 10 ~ 80% RH Storage 10 ~ 90% RH” |
| Reliability | |
| Thermal Print Head (TPH) | |
| Auto Cutter | |
| Platen Roller | |
| Software | |
| Emulation | SLCS™, BPL-Z™, BPL-E™, BPL-D™ |
| Driver/Utility | “Windows Driver (Europlus/Seagull) Linux/Mac CUPS Driver Virtual COM USB/Ethernet Driver Utility Program OPOS/JPOS Driver Bartender Ultralite for BIXOLON Label Artist™-II SAP® Device Driver” |
| SDK/Plugin | “Android/iOS/Windows SDK Linux SDK Chrome SDK Xamarin SDK Web Print SDK” |
| Application | “Label Artist™ Mobile (Android, iOS) mPrint App (Android, iOS)” |
| MDM(Optional) | BIXOLON Profile Manager – XPM™, XCM™ (Windows, Android) |
| Fonts/Graphics/Symbologies | |
| Fonts | Bitmap Fonts (10 SLCS™, 16 BPL-Z™, 5 BPL-E™, 9 BPL-D™), Scalable Fonts (1 SLCS™, 1 BPL-Z™, 1 BPL-D™), 23 Code page, Unicode supported (UTF-8, UTF-16LE, UTF-16BE) |
| Graphics | Supporting user-defined fonts, graphics, formats and logos |
| Barcode Symbologies | 1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 |
| Accessories | |
| Standard | Cable-USB |
| Optional | Peeler, Auto Cutter, External Paper Supply, Serial cable |
| Supplies | B-ribbon™, B-band™ |
| RFID | |
| Frequency | UHF, 865 ~ 868MHz (EU), 902 ~ 928MHz (KR, USA) |
| Transmit Power | 1W |
| Modulation | ASK |
| Protocol | ISO 18000-6C(EPC Class1 Gen2) |
| Auto Cutter | Optional |
| Tag Pitch | Min 16mm |
