XQ-840II Thermal desktop 4″printer featuring an 8-inch Android
GET YOUR QUOTE AND DETAILS
Supported payment types:
Overview
| Print Method | Direct Thermal |
| Print Speed | XQ-840ll: Up to 6 ips (152 mm/sec) XQ-843ll: Up to 5 ips (127 mm/sec) |
| Print Resolution | XQ-840ll: 203 dpi XQ-843ll: 300 dpi |
| Print Width | XQ-840ll: Up to 108 mm XQ-843ll: Up to 105.7 mm |
| Print Length | Up to 1,000 mm |
| Sensor | Transmissive, Reflective (Adjustable), Head Open |
| Media Characteristics | |
| Media Type | Gap, Black Mark, Notch, Continuous, Fan-Fold |
| Media Width | 15 ~ 118 mm |
| Media Roll Diameter | Up to 130 mm |
| Media Thickness | 0.06 ~ 0.20 mm |
| Supply Method | Easy Paper Loading |
| Inner Core | 25.4 ~ 38.1 mm (With Wall Mount Bracket: 25.4mm) |
| Ribbon Characteristics | |
| Ribbon Type | – |
| Ribbon Width | – |
| Ribbon Length | – |
| Core Inner Diameter | – |
| Physical Characteristics | |
| Dimensions (WxLxH) | 194 x 273 x 214 mm (7.63 x 10.74 x 8.43 inch) |
| Weight | 2.42 kg (5.34 Ibs.) |
| Electrical | EnergyStar Certified, External Power Adapter 100-240 V AC, 50/60 Hz |
| Display | 8-inch IPS TFT Touch LCD (800 x 1280 pixels) Android 13 |
| Camera | 2MP Auto focus |
| Performance Characteristics | |
| Memory | Printer: 512 MB SDRAM, 512 MB Flash Tablet: 4 GB RAM, 64GB Flash |
| Interface | USB + 2 USB Host + WLAN + Bluetooth ————————————————— USB : For printer 2 USB Host, WLAN, Bluetooth : For tablet WLAN:802.11a/b/g/n/ac (Infrastructure, Ad-hoc, Wi-Fi Direct, SoftAP) – WEP40/104, WPA1/2 (PSK, EAP) |
| Environment Characteristics | |
| Temperature | Operating: 0 ~ 40℃ (32 ~ 104℉) Storage: -20 ~ 60℃ (-4 ~ 140℉) |
| Humidity | Operating: 10 ~ 80% RH Storage: 10 ~ 90% RH |
| Reliability | |
| Thermal Print Head (TPH) | 12 months or 25 Km (whichever comes first) |
| Auto Cutter | 6 months or 300,000 cut (whichever comes first) |
| Platen Roller | 12 months or max 50 km (whichever comes first) |
| Software | |
| Software | SLCS™, BPL-Z™, BPL-E™, BXL/POS |
| Driver/Utility | Windows Driver (Europlus/Seagull) BIXOLON Utility |
| Developer Tools | Android/Windows SDK, Web Print SDK, Xamarin SDK, MAUI(Multi-Platform App UI) SDK, React Native SDK, Cordova Plugin, Flutter Plugin |
| Design & Print | Label Artist™ Mobile Label Artist™ Web Food Labelling App mPrint App |
| MDM (Optional) | BIXOLON Profile Manager – XCM™ (Android) |
| Fonts/Graphics/Symbologies | |
| Fonts | “Bitmap Fonts (10 SLCS™, 16 BPL-Z™, 5 BPL-E™), Scalable Fonts (1 SLCS™, 1 BPL-Z™), 23 Code page, Unicode supported (UTF-8, UTF-16LE, UTF-16BE) “ |
| Graphics | Supporting user-defined fonts, graphics, formats and logos |
| Barcode Symbologies | “1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB 2D: Aztec, Codablock, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code, TLC 39 “ |
| Accessories / Supplies | |
| Included in the Box | AC/DC Adapter, Power-Cord, USB-Cable |
| Options & Accessories | Peeler, Auto Cutter, Wall Mount |
